Color: Gray
Width: 20 mm
Height: 76 mm
Length: 70.5 mm
Unit Weight: 123 g
Current Rating: 150 A
Mounting Style: DIN Rail (NS 32, NS 35/7.5, NS 35/15)
Voltage Rating: 1 kV
Wire Gauge Max: 1/0 AWG
Wire Gauge Min: 6 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 6 AWG to 1/0 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
