Color: Gray
Width: 16 mm
Height: 65.1 mm
Length: 61.2 mm
Unit Weight: 57.140 g
Current Rating: 125 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 1 kV
Wire Gauge Max: 1/0 AWG
Wire Gauge Min: 16 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG to 1/0 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
