Color: Gray
Width: 6.2 mm
Height: 65 mm
Length: 69.9 mm
Unit Weight: 18.434 g
REACH - SVHC: Details
Current Rating: 30 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 800 V
Wire Gauge Max: 10 AWG
Wire Gauge Min: 26 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 26 AWG to 10 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
